Key Features

    BUILD QUALITY

  •  Superior built quality with long-lasting life
  •  Aesthetic, wide & versatile designs
  •  Easy & economical installation
  •  Bend - proof panels
  •  Paperless & fully sustainable
  •  Highly moisture & fire resistant
  •  Customized creations
  •  Free from termite & vermin
  •  Available in Z-black color
  •  T-grid & joint less installation systems
  •  Ceilling & wall installation
  •  Modified curved panels
  •  Reinforced with pre-stressed glass fiber
  •  Boot time crack-free drop tested
  •  Exposed gypsum surface
  •  Class 0' fire resistant

    SUSTAINABLE PRODUCT

  •  Made of gypsum & glass fiber
  •  No use of paper
  •  Sun-dried panels
  •  Safe material
  •  100% recyclable & incombustible
  •  Enhanced indoor climate conditionfa

Description

Galactic Design Excellence: Seamless Installation with Gypsonic Big Board

Embark on a celestial journey with Galactic, the acoustical masterpiece that redefines ceilings.

Tailored for seamless screw fixing installation, Galactic boasts a stellar design featuring scattered perforations in three distinct diameters: 8mm, 15mm, and 20mm. Inspired by the cosmos, Galactic's perforations extend to the edges, creating a seamless, unified appearance.

With dimensions of 1195x595mm, Galactic introduces "Gypsonic Big Board: Galactic," where magnificence knows no bounds.

Innovative Jointing Method: Elegance Fused with Ease

Simplify installation with Galactic's unprecedented jointing method that eliminates specialized compounds.

Achieve flawlessly levelled surfaces effortlessly, using water-soluble acrylic paint for a seamless finish that preserves its acoustic prowess.

Galactic combines exceptional design with hassle-free installation, revolutionizing acoustical ceilings.

Unmatched Durability with GRG Material: Galactic's Resilience

Galactic's strength emanates from GRG (Glassfiber Reinforced Gypsum) material, celebrated for moisture resistance, fireproofing, and antibacterial properties.

Galactic defies adversity, enduring diverse environments while ensuring longevity.

This material choice cements Galactic as a symbol of reliability across applications.

Elevating Acoustic Comfort: Galactic's Sonic Haven

Galactic transforms acoustic landscapes, excelling in both aesthetics and function.

Its meticulous design and GRG composition synergize to create serene environments, effectively reducing noise and echoes.

Specification

Size 1195 x 595 mm (+/-3mm)
Thickness 12 mm
Weight 3.85 - 4.25 kg
Packing 4 Panels
Compressive Strength 7.6 N/mm2
Static Bending 4.7 N/mm2
Fire Propagation Non Combustible
Class 0
Flame Spread Class 1

Seamless

G.I. Ceilling Section : 85x25 mm

Intermediate : 45x15 mm

L-Wall Angle : 22x12 mm

Smoke & Toxic Fume Rate 0
N.R.C. Value 0.60
0.75
(With 50mm Mineral Woll Back)
S.T.C. Value 35
K-Value (THermal Conductivity) 0.45 W/mK
RH Value (Humidified Deflection) RH99
Static Bending 4.7 N/mm2
Fire Propagation Non Combustible
Class 0
Flame Spread Class 1

Documents

Product Brochure

Gypsonic© | Datasheet

Test Reports

Gypsonic© 12 Material Property Tests

Gypsonic© Anti-Bacterial Test Report

Gypsonic© Fire Class 0 Certification Test Report

Gypsonic© NRC Test Report

Gypsonic© Rh 99 Humidity Resistance Test Report

Installation Guidlines

Gypsonic© | Fully Perforated | T-Grid Installation

Gypsonic© | Fully Perforated | Screw Fixed Ceiling Installation

Gypsonic© | Fully Perforated | Screw Fixed Wall Installation

Gypsonic© | Fully Perforated | Fitting Accessories Specifications
